PAYLOAD:
Max 5 Ton
CHASSIS:
5 wheels structure made in high quality steel, with internal counterweights
WHEELS:
Front: n°4 super elastic wheels 16x7 – R8” Rear: n°1 super elastic wheel 23x10 – R12”
TRACTION:
Rear traction with electric motor DC 7 kW
HYDRAULIC SYSTEM:
Powered by electric motor DC – 5 kW maximum pressure 210 bar
BRAKES:
N°1 brake shoe on rear wheel
STEERING:
Rear steering by hydraulic engine installed on fifth wheel
BOOM:
Manufactured in high quality steel, composed by four elements: main boom and three telescopic hydraulic sections
BATTERY:
48V - 575 Ah
CONTROLS:
Traction: By pedals and steering wheel inside the cabin
Boom: By proportional distributor with levers inside the cabin
SECURITY (LMI):
Electronic Load Moment Indicator. Display showing lifted load, max allowed load, tilting percentage, operating radius, angle, telescope and light indicators on the operative mode
TOTAL WEIGHT:
5.500 Kg
OPTIONALS:
Hydraulic winch, manual Jib, hydraulic Jib, radio remote control, non marking wheels, chain hoist, battery watering system, on board battery charger, carry deck, closed cabin
